技術參數

◎規格：端鈕盒銅條，小A(8×10.5)、中A(9×11、10×12)、

   大A(11×13)

◎脈沖信號線：2、4、6、8線或2、4插片

◎電流配置：5（30）A帶1-8組輔助端口

                     10（60）A帶1-8組輔助端口

                     20（100）A帶1-8組輔助端口

◎說明：采用塑料鉛封，端子外置，可選配多種標牌、各種防竊

    蓋、壓接式端鈕盒，拆分式端鈕盒。

TECHNICAL PARAMETERS

◎Specifications: copper bar of terminal box, small A(8×10.5), middle

    A(9×11,10×12),large A(11×13)

◎Pulse signal lines:2,4,6,8 lines or 2,4 plug-in pieces

◎Current configuration: 5(30)A with 1-8 sets of auxiliary ports

                                       10(60)A with 1-8 sets of auxiliary ports

                                       20(100)A with 1-8 sets of auxiliary ports

◎Note: it uses plastic seals with external terminal, it can be optionally

    equipped with a variety of signs, all kinds of anti-theft cover, crimp

    -type terminal box and split-type terminal box.
