技術參數

◎規格：壓接式端鈕盒，小A(1.5mm銅片)

◎脈沖信號線：1-10接線端子

◎電流配置：1.5(6)A帶1-10組輔助端口

◎說明：原創設計，采用電能表接線方式，方便快捷，成本大幅

    度降低，防塵防潮設計，另可配各種阻值互感器。

TECHNICAL PARAMETERS

◎Specifications: crimp-type terminal box, small A(1.5mm sheet copper)

◎pulse signal lines: 1-10 terminals

◎Current configuration: 1.5(6) A with 1-8 sets of auxiliary ports

◎Note: with original design, it uses energy meter wiring method which

    is convenient and cost saving, dust-proof design can be equipped

    with a variety of resistance shunt.
